X-ray diffraction

X-ray diffraction (XRD) is a method used for studying the structure, composition, and physical properties of materials by analyzing their crystal structures. With XRD analysis, it is also possible to identify crystalline materials. The technique is commonly applied in materials science, but it can also be used in product development and production process optimization in multiple industries.

XRD
...and more than 700 other happy clients

Some of our XRD services

Powder XRD measurement - Quantitative analysis

Phase identification and quantification (Rietveld analysis) of a crystalline powder material using X-ray diffraction (XRD). The analysis can also provide unit cell dimensions. The analysis is only suitable for materials with at least one crystalline phase. The quantification accuracy is roughly 0.1 %, depending on the sample matrix and the phase in question. The available temperature range for XRD measurements is 25-1100 °C and the crystallinity can be studied as a function of temperatures. The measurements can be done under a normal atmosphere, inert gas, or vacuum. Please contact our experts to discuss the available temperature and atmosphere combinations. Please mention which crystalline phases your material contains and which ones are you interested in quantifying when requesting testing. However, the method can be applied to unknown phases as well. Either a tabletop or a synchrotron XRD can be used to perform the measurements.
189–569 €
Read more

Substances of very high concern (SVHC) analysis

The substances of very high concern (SVHC) analysis provides comprehensive material screening for SVHC substances as listed in the Registration, Evaluation, and Authorization of Chemical Substances (REACH). The maximum allowed concentration of any substance on the SVCH list is 0.1 mass-%. If the product contains more than 0.1% w/w of an SVHC substance, ECHA has to be notified and information on the safe use of the article must be provided to customers upon request. Contact us to request a quote for screening your material for SVHCs. The price of the analysis depends on the sample type.
400–600 €
Read more

Powder XRD measurement - Qualitative analysis

Qualitative or comparative analysis of crystalline powders using X-ray diffraction (XRD). The analysis is only suitable for materials with at least one crystalline phase.
97–241 €
Read more

Respirable crystalline silica (quartz) content of materials

Analysis for determining the content of respirable quartz and other forms of respirable crystalline silica in products and materials. The results can be used for labeling purposes and to facilitate the development of safer products. Crystalline silica/quartz is a common ingredient in building products and other materials containing or composed of stone, gravel, clay, or sand. Exposure to respirable silica for extended periods or high exposure for short periods causes silicosis and may lead to the development of lung cancer. This is why a binding limit value has been set for workplace exposure to respirable crystalline silica in EU countries. Ensuring that materials have a low quartz content is the most effective and cost-efficient way to prevent respirable quartz exposure. In EU countries, materials containing crystalline silica and other category 1 carcinogens are subject to a classification obligation, unless carcinogens are present in quantities below 0.1 % (w/w). Consequently, such products should include the warning “May cause lung cancer by inhalation” and “Causes damage to lungs”. The obligation applies to chemically modified mineral products that contain quartz. Additionally, industrial mineral producers (IMA) in the EU have decided that even non-modified mineral products should be classified based on their crystalline silica content (fine fraction), provided the content exceeds 1.0 wt.%. Please contact the expert team through the form below for more details on the analysis.
1,127 €
Read more

Single crystal XRD

Single crystal X-ray diffraction (SC-XRD) can be used to obtain highly detailed information on the crystal structure of the samples, such as the arrangement of atoms, bond lengths, angles, and symmetry of the crystal lattice. The method is suitable for a variety of different materials such as metals, ceramics, organic materials, and metallo-organic complexes. The analysis can be performed on crystalline samples with a minimum crystallite size of 0.1 mm. Before analysis, we will check the sample under a microscope for a suitable crystal. Please mention which elements the sample contains and the expected crystal structure of the sample.
Read more

XRD analysis of bentonite

EN 13925
Quantitative mineralogical analysis by X-ray powder diffraction (XRD) on bentonite samples to identify and quantify the concentration of occurring minerals. The analysis is performed according to EN 13925. The results of the analysis are expressed as percentages, for example: % of Smectite, % of Quartz, % of Calcite, % of Opal, % of Feldspar. The uncertainty of the measurement is 10–20%.
564 €
Read more

Prices excluding VAT.

  • Fast turnaround times
  • Personal service from method experts
  • Competitive prices
  • Result accuracy guarantee

What is X-ray diffraction used for?

X-ray diffraction (XRD) is used to determine the properties of the crystallographic structure (i.e. crystal structure) of crystalline materials. Crystal structure means the order of the particles (atoms, ions, or molecules) in a crystalline matter, where they are arranged into regular arrays of repeating unit cells.

Sodium chloride (table salt) and diamond are examples of crystalline matter. The components of crystalline solid structures are usually crystal planes, i.e. atoms that have settled as planes on top of each other at certain distances, specific to that certain structure. These distances can be measured with XRD.

How does XRD work?

XRD is based on a phenomenon called diffraction. In diffraction, a regular array of scatterers produces a regular array of spherical waves of radiation when they interact with radiation. This is called elastic scattering. In almost all directions, the produced waves cancel each other out, which is called destructive interference. However, in a few specific directions, the waves add and amplify each other, which is called constructive interference. These specific directions appear as bright spots called reflections on the formed diffraction pattern.

Diffraction can be applied to the atomic level of different materials when X-rays are used as electromagnetic radiation to produce the diffraction pattern. In XRD, the X-rays scatter from the atoms in the crystal structure primarily because they interact with the electrons in the atoms. The diffraction pattern produced by the diffracted X-rays is different for every substance because of the unique order of the atoms or molecules in them.

The intensities and scattering angles of the X-rays diffracted from the material are measured with an X-ray analyzer. The final result of the measurement is a diffractogram, which is a plot that has the X-ray intensity on the y-axis and the angle between the incident and the diffracted X-ray beam on the x-axis. When the angles where the constructive interference happens and the reflections occur are measured and the wavelength of the used X-rays (λ) is known, the distances between the crystal planes or atoms in the material (d) can be calculated using the mathematical formula of Bragg’s law.

Information obtained through X-ray diffraction

Various types of information can be obtained using XRD analysis. Because every crystalline matter produces its own kind of diffraction pattern and thus diffractogram, different materials can be identified by comparing the obtained diffractogram with commonly used reference databases containing known crystal structures of different materials.

It is also possible to determine the relative amounts of components in a material that consists of several different phases or substances. The lattice parameters of particles in a crystalline structure can be determined with XRD, as it is possible to measure the dimensions, shapes, and geometries of the particles in the material.

Rietveld refinement can be used to accurately quantify the components within a sample by fitting a theoretical model of known crystal structures to the XRD pattern of the sample. This allows for a more precise estimation of the amount of each phase present.

Additionally, the crystallite size and strain can be measured with XRD, because the width of the bright spots in the diffraction pattern depends on the crystallite size of the matter and microstrain in the sample. Single crystals can also be investigated to determine the three-dimensional structure of their molecules with the help of single-crystal diffraction (SCD). This analysis requires a single crystal from the sample which can be produced by varying conditions like solvent or evaporation rate.

Non-ambient XRD

X-ray diffraction measurements can be done under ambient or non-ambient conditions. In non-ambient XRD (NA-XRD), the sample is analyzed under different conditions which can be created by adjusting environmental parameters such as temperature, pressure, relative humidity, gas environment, mechanical load, as well as electrical and magnetic fields.

The altering of the parameters in NA-XRD results in changes in the material and its structures and these changes can be examined as they happen. For example, structural changes during operation, heat treatment, calcination, and sintering, as well as hydration and dehydration processes can be studied with this method.

High-temperature XRD (HT-XRD) is one of the most commonly used NA-XRD methods to understand phase transitions, track decompositions, and understand how the material responds to high temperatures. Some instruments allow temperature-programmed experiments, where the temperature is gradually increased while collecting XRD data, revealing how the material's structure evolves with heat.

Samples

For diffraction to occur, X-rays have to scatter from a regular array of particles that have a long-range order in the material. This is why the samples have to be solid crystalline materials with a regular crystal structure. Amorphous materials can also be examined with XRD but only a limited amount of information is obtained from them.

It is possible to pretreat the samples before analysis by grinding them into powder. This improves the quality of the measurement by increasing the diffraction intensity of the X-rays.

For thin film characterization, the closely related GIXRD method is a better match. Another option for investigating crystal structures is EBSD analysis.

Suitable sample matrices

  • Solid samples
  • Crystalline materials
  • Metals
  • Alloys
  • Ceramics
  • Polymers
  • Minerals
  • Zeolites
  • Catalysts
  • Pharmaceuticals
  • Active pharmaceutical ingredients (APIs)
  • Foods

Ideal uses of XRD analysis

  • Material examination, such as analyzing crystal structures or phases and structural changes in variable conditions
  • Industrial research and product development in industries like mineralogy, metallurgy, chemical industry, and food industry
  • Material identification
  • Quality control
  • Failure and defect analyses, such as internal stress measurements
  • Optimization of production processes

Ask for an offer

Fill in the form, and we'll reply in one business day.

Answering the following questions helps us prepare an offer for you faster:

  • How many samples do you have and what is the sample material?
  • Do you have a recurring need for these tests? If yes, how often and for how many samples at a time?

Have questions or need help? Email us at or call our sales team.

Frequently asked questions

What is XRD commonly used for?

The most commonly used application of XRD is the identification of materials based on the diffraction pattern and diffractogram of the reflected X-rays. XRD is also used for determining the structural properties of the material, including grain size, lattice parameters, strain, preferred orientation of the particles, and phase composition.

Non-ambient XRD (NA-XRD) is widely used in research and product development in various fields of industry, such as mineralogy, metallurgy, ceramics, chemical industry, pharmacological industry, and food industry.

Additionally, thin films and coatings can be analyzed with grazing incidence X-ray diffraction (GIXRD), which is a version of XRD.

What is GIXRD?

Grazing incidence X-ray diffraction (GIXRD) is a modification of XRD having the same operating principle as XRD. With GIXRD, the crystal structure and particle level properties of thin films and coatings can be analyzed by adjusting the incident angle of the X-ray beam hitting the sample relative to the critical angle of the reflected X-rays. The phenomenon works in the same way as in X-ray reflectivity (XRR), with which the structural properties of thin films can be determined.

When small enough incident angles of the X-ray beam are used, a stronger signal from the surface layer of the material is created, in which case the particle-level structure of thin films and coatings can be discovered and the substances in them can be identified. Therefore, GIXRD can be a helpful tool in the product development and quality control of different coatings, for example.

What are the limitations of XRD?

When an unknown material needs to be defined properly, the sample should be homogenous or its composition should be consistent. Identification of unknown sample materials also requires a reference data library.

XRD is best suited for samples consisting of crystalline material. The measurement also works out for amorphous matter, but the amount of information obtained from it remains small. If the sample consists of many different crystalline components, the diffractogram may be too complex to analyze the repeating unit cells or particles of the material. In addition, some samples need to be ground in order to obtain good enough data.

The crystal structure of thin films cannot be determined with the ordinary XRD method. Instead, grazing incidence X-ray diffraction (GIXRD) is needed for this purpose.

What kinds of samples can be analyzed with XRD?

In order for the diffraction to occur, the X-rays have to scatter from a regular array of particles that have a long-range order in the material. This is why the sample material has to be solid and preferably crystalline.

With non-ambient XRD (NA-XRD), sample matrices like alloys, building materials, ceramics, refractory materials, polymers, minerals, zeolites, catalysts, drug APIs, pharmaceuticals, and foods can be examined.

What is Measurlabs?

Measurlabs offers a variety of laboratory analyses for product developers and quality managers. We perform some of the analyses in our own lab, but mostly we outsource them to carefully selected partner laboratories. This way we can send each sample to the lab that is best suited for the purpose, and offer high-quality analyses with more than a thousand different methods to our clients.

How does the service work?

When you contact us through our contact form or by email, one of our specialists will take ownership of your case and answer your query. You get an offer with all the necessary details about the analysis, and can send your samples to the indicated address. We will then take care of sending your samples to the correct laboratories and write a clear report on the results for you.

How do I send my samples?

Samples are usually delivered to our laboratory via courier. Contact us for further details before sending samples.
