Mechanical testing services

Get laboratory services for mechanical testing of polymers, plastics, composites, metals, textiles, paper & board, and novel materials. Measurlabs offers a full range of mechanical tests from tensile and hardness testing to crush tests and other material-specific analyses.
Laboratory testing services
...and more than 700 other happy clients
  • Fast turnaround times
  • Personal service from method experts
  • Competitive prices
  • Result accuracy guarantee
Plastic and polymer testing

Mechanical testing of polymers

Understanding the mechanical properties of polymers and plastic materials is critical in allowing product developers to know how their material performs in the desired application. Measurlabs offers mechanical testing for all kinds of plastic and polymeric materials ranging from tensile, flexural, compression, shear, creep, dynamic (DMA), friction, scratch, hardness, fatigue, impact properties, and many more. Depending on the product, the test method can be chosen from various testing standards or by using custom methods.

Coefficient of friction of plastic films

ISO 8295
The method measures the coefficients of starting and sliding friction of plastic films and sheeting when sliding over the same or another material. The testing procedure is based on the ISO 8295 standard. The measurement can be used for quality control of plastic film samples. Four replica measurements per sample are included in the displayed price.
503 €
Read more

Density determination of plastics and polymers

ISO 1183-1
In this analysis, the density of plastics and polymers is determined by the immersion method specified in part A of the ISO 1183-1 standard. The method is suitable for plastic granulates and for products and materials delivered as sheets that can be cut into the right shape in the lab. If the sample is delivered as granulates, the test objects are prepared in the lab by injection molding. The price includes sample preparation.
134 €
Read more

Tensile properties of rigid plastics by ISO 527-2

ISO 527-2
Tensile test for extrusion and injection molded plastics at room temperature. The test characterizes the tensile modulus, yield point, and point of break in accordance with the EN ISO 527-2 standard. The price includes the testing of five A1-type specimens (a sixth specimen is required as backup). Sample preparation is not included in the price, therefore samples should be delivered ready for the test. The standard test parameters are as follows: Clamping pressure: 3 bar, Test speed: 50 mm/min . Other parameters can be used upon request.
160 €
Read more

Flexural properties of plastics - 3-point bend test by ISO 178

ISO 178
Determination of the flexural properties of rigid and semi-rigid plastics and composite materials using 3-point bending tests according to the ISO 178 standard. Results include the following parameters: Conventional deflection, Flexural modulus, Flexural strength at conventional deflection, Flexural strength, Flexural strength at break, Bending at conventional deflection, Bending at break. The displayed price covers testing at room temperature. Other temperature programs are available for an extra charge.
160 €
Read more

Prices excluding VAT.

Airplane wing composite testing

Mechanical testing of composites

Composite products often need to comply with demanding quality standards of various industries, such as the automotive, construction, and aerospace industries. Measurlabs can offer industry-specific destructive and non-destructive (NDT) composite testing to determine properties such as tensile strength, hardness, toughness, impact strength and compressive strength, and to detect underlying defects in the structure.

Cardboard boxes

Mechanical testing of paper, paperboard and corrugated cardboard

At Measurlabs we offer testing of paper, board and packaging materials according to ASTM, ISO, DIN and TAPPI standards. Our service includes measurements such as bursting strength, SCT, ECT, FCT, bending stiffness, internal bond strength, air permeance, tensile strength, optical properties, and many others that are essential in the quality assurance of existing products and product development of novel biobased materials.

Short-span compression test (SCT) for paper or board

SCT (short-span compression test) is one of the most commonly used testing methods for determining the compression strength of paper or cardboard. In this test, the sample is conditioned in standard conditions (23 °C/50% RH), after which the compression strength is measured in the machine direction (MD) and the cross direction (CD).
80 €
Read more

Tensile strength (TEA) of paper and paperboard

This test is used to measure the tensile strength and elongation of paper or board in the machine direction (MD) and the cross direction (CD). Even small variations in tensile strength can affect the functionality of the product. Paper and board must withstand certain forces during manufacturing, transportation, shipping, and use.
78 €
Read more

Bending stiffness of corrugated cardboard

Bending stiffness testing is performed to evaluate cardboard's stiffness by measuring the resistance to bending with 4-point loading. The results express the bending stiffness of the material in the machine direction and the cross direction.
95 €
Read more

Pin adhesion test (PAT) of corrugated cardboard

PN 87/P-50143/07
The pin adhesion test measures the bond strength between the corrugated medium and the liner. It is used to analyze the strength of adhesives. Upon request, the measurement can be performed on double-walled and triple-walled corrugated cardboard.
215 €
Read more

Puncture resistance of corrugated cardboard

ISO 3036
In this test, a pyramid-shaped puncture head is used to measure the puncture resistance of a board sample. During this process, combined tensile, compression, flexural, and shear forces occur. The result is given as the energy absorbed by the sample upon being punctured. If you need a puncture resistance test for another material, please contact us to request an offer.
90 €
Read more

Prices excluding VAT.

Textile colour fastness

Mechanical testing of textiles

Textile testing plays an important role in making sure that the product is suitable for its designated end-use application and complies with the required specifications. Measurlabs offers a wide selection of mechanical testing for textiles, ranging from single fiber tests to testing of readily assembled clothing.

Coating adhesion of textiles

EN ISO 2411
Test according to the ISO 2411 standard to determine the coating adhesion strength of fabrics coated with rubber or plastic. Knowing the adhesion strength of the coating to the fabric is an important quality indicator, as poor adhesion strength may result in product failure.
111 €
Read more

Crease resistance of dry textiles

DIN 53890
This test is used to determine the crease recovery angle of textiles.
94 €
Read more

Prices excluding VAT.

Metal testing / roof

Mechanical testing of metals

Metallic components, especially those used in construction and load-bearing structures, often need to meet strict mechanical specifications. We at Measurlabs offer a wide range of mechanical testing for your metallic products. Some of our methods include tensile testing, fatigue testing, coefficient of thermal expansion (CTE) determination, creep testing, and hardness testing.

Linear thermal expansion of solids with a rod dilatometer

ASTM E228
A dilatometer is used to determine the linear thermal expansion of a material as a function of temperature. The temperature range of the measurement is generally between 25 °C and 1,600 °C. There is also an option to perform the test in a cryogenic atmosphere, which ranges from -175 °C to 300 °C. The typical heating rate is 3 °C/min. As a result of the measurement, you will get the coefficient of thermal expansion (CTE) and the absolute change in sample length, both as a function of temperature. The testing can be performed in various atmospheres, including air, argon, CO2, N2, and O2. Please contact us to get a quote. The price will depend on the testing conditions, so please specify them as precisely as possible.
Read more

Hardness testing of metals

ISO 6506-1, ISO 6507-1, ISO 6508-1
Indentation hardness testing measures a material's ability to resist plastic deformation. We offer 3 different types of tests: Brinell hardness testing (ISO 6506-1), Vickers hardness testing (ISO 6507-1), Rockwell hardness testing (ISO 6508-1). These methods work by pressing a standard-sized test head into the sample and measuring either the size of the indentation or the penetration depth of the indentation tip. Each method is suitable for all types of metals and alloys.
45–75 €
Read more

Tensile testing of metals at room temperature by ISO 6892-1

ASTM E8, EN ISO 6892-1
Tensile tests are the most common way to determine the tensile strength, ductility, and toughness of a material. The tests are performed according to ASTM E8/E8M and ISO 6892-1 standards. The results include data on multiple properties, including tensile strength, yield strength, and modulus of elasticity. Standard samples require a minimum 75 mm length and 5 mm diameter, although smaller samples can be measured upon request. The machining of samples can be included in the analysis. We also offer tensile tests at elevated temperatures.
89–185 €
Read more

Prices excluding VAT.

Ville Roininen

Questions?

Ville Roininen is happy to answer all your questions.

+358 40 752 5289

Looking for something else?

There are many more analyses in our full offering, and our expert team is happy to help with any questions regarding testing methods and sample suitability. Contact us directly with your questions or send us an offer request through the form below. We will get back to you within one business day.

Why choose Measurlabs?

Widest range of testing methods – get all your tests done in the same place.

Best laboratories – for every test, we have sourced the best lab for that particular method, which means that you get the most accurate results and the best price.

Personal service – get help from method experts if you are unsure about standards, your testing needs or sample suitability.

Tell us about your needs and get a quote

Fill in the form, and we'll reply in one business day.

Answering the following questions helps us prepare an offer for you faster:

  • How many samples do you have and what is the sample material?
  • Do you have a recurring need for these tests? If yes, how often and for how many samples at a time?

Have questions or need help? Email us at or call our sales team.
